  • Altair 2″ Filter Holder T2 to T2 & Filter Slider, Version 2 - 17 mm short
  • Altair 2″ Filter Holder T2 to T2 & Filter Slider, Version 2 - 17 mm short

    • Číslo produktu: MAGF2-T2
    • Výrobce: Altair
    • Váha dodávky: 0.12 kg

    Cena s DPH: 4 695,-
    1-2 týdny
    Hlídat dostupnost - Altair 2″ Filter Holder T2 to T2 & Filter Slider, Version 2 - 17 mm short
    Chci být informován až bude zboží skladem

    *

Filter change in a few seconds without removing the camera, ideal for astrophotography - the filter holder is the compact and lightweight alternative to the filter wheel.

♦ Connection telescope side: T2 - M42x0.75 female thread
♦ Connection camera side: T2 - M42x0.75 external thread
♦ Overall length only 17 mm
♦ Weight only about 120 grams, the focuser is not loaded
♦ Diameter 80 mm - adapter threads are exactly centered
♦ Ideal also for telescopes with the camera in front of the optics, like Celestron RASA or Hyperstar systems
♦ Precise locking of the filter slider by magnet
♦ The filter can be easily screwed into the slider
♦ The set includes the filter drawer and a filter slider for 2″ filters.
♦ Additional filter sliders available for 1,25″ and 2″ mounted filters

Altair Mgnetic Filter Drawer Version 2 - manual Filter Change within Seconds

Altair offers with the 2″ Filter Holder a very advanced drawer with many useful product features. Especially astrophotographers who do not want a large and partly heavy filter wheel will find an exciting alternative with this filter drawer. In spite of the compact and above all lightweight construction, this filter holder does not have to be without stability and accuracy.

♦ The optical length is only 17 mm.
♦ The filter slider snaps into place magnetically, guaranteeing precise positioning of the filter.
♦ Thanks to the open design of the slider, the filter can be easily inserted or removed.
♦ The drawer is round and very compact, so that it can also be used in front of the optics, for example in Hyperstar systems or Celestron RASA.
♦ A filter slider for 2″ filters is included in the scope of delivery.
♦ Thanks to additional filter sliders (optional) for 2″ and 1,25″ filters, you can combine any filters with each other.

Applications of the Altair filter drawer:

♦ Deep sky astrophotography: L-RGB shots, false color shots, contrast enhancement through nebula filters with mono or color astro cameras and DSLRs
♦ Planetary observation and planetary imaging: quickly change color filters to enhance contrast. In photography, the photos can be combined well later.
♦ Deep sky observation: the impressions without filter, with UHC filter, O-III filter and other filters can be directly compared with each other. So you always get the maximum of details out of the observed object!

Practical tips from Teleskop-Service:

♦ Especially with adaptations for astrophotography it often depends on the fraction of a millimeter. With our tuning rings and extension rings you can adapt the filter drawer exactly into your "image train".
♦ We recommend one drawer per filter. Unscrewing filters during photography or observation is rather impractical.
♦ The FIPA92 protective container offers optimum storage, so that the filters are always at hand and are stored gently.

Note: Order extra version 2 sliders to fit Version 2 magnetic holders because they have the correct polarity.



Connection telescope side: M42x0.75 - T2 internal thread - length 4 mm
Connection camera side: M42x0.75 - T2 external thread - length 4 mm
Effective overall optical path: 17 mm (without external thread)
Supplied slider suitable for filters: 2″ mounted (M48x0.75)
Holder diameter: 80 mm
Weight: approx. 120 gram
